Unit height as low as 212mm for installation at limited ceiling space.
Product category:
Fan Coil Unit›Ceiling Convertible Type
Salient Features
Auto Air Swing
The motorized louver enables the air flow to be evenly distributed.
Auto Restart with Last-State-Memory
In case of sudden power failure during operation, unit restarts automatically & unit will operate based on previous setting when power is resumed.
Ceiling and Floor Installating Option
The unit is uniquely designed with possiblity to be installed under or sitting on the floor to suit any interior design requirements.
Choices Of Wired Or Wireless Remote Controller
Compact and user friendly wireless BRC52A and wired BRC51A remote controller offer :
• Real Time Clock • "Glow in the dark" ON/OFF Button • Low, Medium, High fan speed options • ON Timer Setting
Compact Design
Ceiling Cassette C Series body dimension is only 570 mm x 570 mm which can easily fits into a 600 mm ceiling grid.
Far Air Throw
Maximum air throw distance up to 16.5m.
NIM-Able
Able to communicate with the versatile NIM networking control module and offers the oppurtunity of one centralized control for a system of multiple indoor units in a building.
Room Temperature Sensing
Able to sense the room temperature in order to perform more controls for comfort.
Saranet Air Filter
The anti fungus air filter removes air-particles from the air.
Self Diagnosis Features
This feature helps to detect any faults or malfuctioning in the system and provide user a warning by blinking of the LED lights.
Service & Maintenance at Ease
The washable fitler can be easily accessed by just pulling down the intake grill. During servicing or repairing, only the bottom panel needs to be removed in order to access the parts like fan motor, blower, wiring connection, control box, piping connection and so on.
Sleep function for Cool and Heat mode
Once activated, set temperature will be increased / decreased gradually according to normal sleeping temperature patterns to ensure a comfortable sleeping environment.
Valve Or Valveless Control Options
The design is flexible enough to allow for either valve or valveless control installation.
Versatile Installation
The unit is designed to work with high pressure head drain pump (optional). Thus offering flexibility for installation on condensate drain pipe. The drain pump comes with a high head and is incorporate with the float switch as safery protection. Drain pump kit supplied as optional item
